| Brand Name : | Shelok |
| Model Number : | SLK- MH-F / FP |
| Price : | USD+450~560+Piece |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 100+pieces+per month |
| Delivery Time : | 5-8 work days |
MH-F / FP split wireless ultrasonic water tank level meter produced with our many years experience of level meter production . drawing on a variety of similar products advantages, and the development of a convenient and applicable split ultrasonic level meter, Environmental machine circuit is prone to trouble to worry about. With accurate measurement, reliable work, the appearance of generous and so on. Using large-scale integrated circuits, component chip rate of 90%, to ensure the long-term reliability of the product. While reducing its power consumption to a very low, the use of large-screen display full Chinese menu easy to use, support SD card data acquisition and serial data download, can record ten interference echo points.
1.International electrical interface easy to take.
2.The sensor is strong and stable for harsh industrial situations.
3.Strong anti-interference
4.4~20MA current output, optional field bus interface
5.Can manually set blind area
6.Support blue-tooth ,GPRS,Mini SD card ,USB ,Mini printer (option)
Specification of digital high precision ultrasonic deep well water
liquid level meter | |||
Range | 2-30m(optional) | Blind area | 0.3~ 1.5m |
Minimum display resolution | 1mm | Frequency | 20 KHz～200KHz |
Accuracy | ±0.3%F.S | Display | Chinese and English bilingual LCD, colourful TFT(option) |
Analog signal output | 0～20mA；4～20mA>300Ω； 0～5V；0～10V | Sensor material | 10m shielded cable (option the length ) |
Switch output | 2 lines NPN/Relay(AC:5A 250V DC:10A 24V) | Work power | DC12—24V or AC220V |
Case Material | ABS plastics,Nylon | Interface | G1 1/2, M60×2 ,M30X1.5 or DN80 non-stander flage(Range 20m-30m) |
Protection grade | IP65 and EXiaII BT4Gb | ||
1. Water industry (pumping stations, biochemical reaction pool,
sedimentation tank etc.)
2. Electric power, mine industry
3. Food industry
|
|
