| Brand Name : | Shelok |
| Certification : | CE |
| Price : | USD+54~64+piece |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 100+pieces+per month |
| Delivery Time : | 3-15 work days |
SLK-110 differential pressure transmitter detect differential
pressure or gauge pressure then convert this pressure difference to
a proportional analogue output signal. Two output version are
offered: Voltage output of 0~10VDC, and a current output 4-20mA.
differential pressure transmitter ranges from 0~±50Pa to
0~±10000Pa. These transmitters boast of their outstanding
performance,high quality and economical pricing.
Specification of micro differential pressure transmitter | |||
Medium | Dry gas | Material | Aluminium alloy |
Measuring range | -10~0~10KPa | Maximum static pressure | 70KPa |
Overload capativity | 200%FS | Pressure type | Differential pressure |
Output signal | 4-20mA,0~5V,0~10V,1~5V,RS485 | Power supply | 9~36VDC(15~36VDC for 0~10VDC) |
Accuracy | 0.25%FS,0.5%FS | Anti-seismic property | 25g(20~2000Hz) |
Respond frequency | ≤500Hz | Stablility performance | ±0.01%FS/year |
Temperature drift | ±0.01%FS/℃ | Ingress protection | IP54 |
Maximum power | Current:≤0.02Us(w);voltage:≤0.008Us(w);digital:≤0.015Us(w);Us=voltage | ||
Load characteristic | Current load≤ Ω(Us-7)/(Us=voltage);Current load≥100KΩ | ||
|
|
