| Brand Name : | Shelok |
| Model Number : | YD-36 |
| Certification : | CE |
| Price : | USD45-75 |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal |
| Supply Ability : | 100+piece+per month |
| Delivery Time : | 5-10working days |
Ceramic pressure sensor without liquid transmission, the pressure directly on the front surface of the ceramic diaphragm, so that the diaphragm has a small deformation, thick film resistance printed on the back of the ceramic diaphragm, connected into a Wheatstone bridge (closed bridge), due to the piezoresistive effect of the varistor, the bridge is generated with a high linearity proportional to the pressure, and the voltage signal is proportional to the excitation voltage. The voltage signal is converted to a 4~20 mA current signal through the modulation amplifier circuit.
1.all stainless steel shell, excellent corrosion performance
2. Wide range of pressure measurement
3. natural frequency up to 1MHz
4.work stable
5. anti-interference ability
6.imported components, reliable performance. The following are the
same as the "
7. small size, light weight, type complete, cost-effective
8.wide range of measuring media
Specification of ceramic low cost water hydraulic pressure sensor: | |||
Measure Range | 100KPa~60MPa | Accuracy | 0.2, 0.5 (20°C) |
Output | Current, Voltage, Digital signal optional | Material | Ceramic + stainless steel 316 |
Overload pressure | 2 times the basic overload | Long stability | ≤±0.2%FS/Year |
Seal | Fluorine rubber seal non-internal seal | Thread | Optional |
Sound frequency | 200HZ | Housing material | Stainless steel structure |
System pressure | 1000% FS | Temp.compensation Range | 0-+70/℃ |
Temperature | Medium temperature -30 ~ 100 °C Ambient temperature -30 ~ 80 °C | Protection | IP65 or IP67 High magnetic compatibility |
Warming | ±0.08FS/°C (4~20mA output) | Pressure type | Absolute or Sealed gauge pressure |
|
|
